HYDRAULIC PRESSURE INTENSIFIERS – MP-M SERIES

Home / Products / Pressure Intensifiers / Reciprocating Type / Hydraulic Pressure Intensifiers – MP-M Series

silver hydraulic pressure intensifier, MPM-F series transparent

Hydraulic Pressure Intensifiers — MP-M Series Type ScanWill IC-Fluid Power, Inc.

Hydraulic Pressure Intensifiers — MPM-F Series Type ScanWill IC-Fluid Power, Inc.

Request a Price Quote

LOW/MEDIUM PRESSURE

Hydraulic Pressure Intensifiers – MP-M Series

The MP-M is an in-line hydraulic intensifier for medium size hydraulic systems.

Key Features of the MP-M:

In-line pressure intensifier, reciprocating type for continuous flow

MP-M Configurations:

Safety valve applications (MPM-350): The MPM-350 is an in-line hydraulic intensifier designed to increase a supplied pump pressure to a higher end pressure (for fluids only). This intensifier is capable of a maximum supply pressure of 350 bar (5,075 psi), as opposed to the MP-M which has a maximum supply pressure of 200 bar (2,900 psi). This can be used for applications where the intensifier is used as a safety valve for closing wells on land.
Hydraulic tongs applications (MPM-F): The MPM-F pressure intensifier is a made to meet the space requirements of a customer for hydraulic tongs in the offshore industry. This series can be used in custom applications as well.

Technical Data:

Inlet Flow:

MP-M: up to 6.6 gpm (35 lpm)
MPM-350: up to 6.6 gpm (25 lpm)

Supply pressure:

MP-M: up to 2,900 psi (200 bar)
MPM-350: up to 5,075 psi (350 bar)

End pressure rating:

MP-M: 290-11,600 psi (20-800 bar)
MPM-350: 7,250-15,225 psi (500-1,050 bar)

Multiple intensification ratios
High pressure valves integrated including a pilot-operated check valve
Weight: MP-M: 7.7 lbs (3.5 kg)

Intensification Ratio Chart (MP-M):

Ratio	Min. Inlet Flow	Max. Inlet flow	Outlet Flow Q1	Outlet Flow Q2	Min. Inlet Pressure	Max. Supply Pressure	Max. Output Pressure
(i)	(GPM / LPM)	(GPM / LPM)	(GPM / LPM)	(GPM / LPM)	(psi / bar)	(psi / bar)	(psi / bar)
1.8	1.9 / 7	6.6 / 25	1.32 / 5	0.39 / 1.5	218 / 15	2,900 / 200	5,220 / 360
3.4	1.9 / 7	9.3 / 35	5	0.74 / 2.8	218 / 15	2,900 / 200	9,860 / 680
4	1.9 / 7	9.3 / 35	1.06 / 4	0.63 / 2.4	218 / 15	2,900 / 200	11,600 / 800
5	1.9 / 7	9.3 / 35	0.93 / 3.5	0.5 / 1.9	218 / 15	2,030 / 160	11,600 / 800
7. 0	1.9 / 7	9.3 / 35	0.8 / 3	0.34 / 1.3	218 / 15	1,450 / 114	11,600 / 800

ScanWill is a supplier and pressure intensifier manufacturer for various applications including construction, mechanical, marine, and industrial.
